wodBeep ActiveX component

Beep ActiveX component


Beep ActiveX implements a a generic application protocol for connection-oriented, asynchronous interactions. It permits simultaneous and independent exchanges within the context of a single application user-identity. It supports compression, SSL/TLS, authentication and more! All through either ready-made or your own profiles!
Free for personal and commercial use.

Beep image

Download

Try it out for 30 days

Get update

Already bought wodBeep? Get latest version here

Release notes

What's new or changed, latest version is 1.0.0

Discuss

View forum discussion

Online help

Browse detailed documentation


Pricing per developer

Single developer license (includes full source code)
USD 439.00
License includes one year of free updates and unlimited lifetime technical support. Each developer must have his own design-time license.

Licensing

Non-source version is free for commercial and noncommercial use. You have the right to distribute wodBeep.DLL binaries with your applications free of charge.

No support is given for this component. If you use this component in your product, your product's license back to us would be a nice gesture - but not required.


General information

BEEP protocol is a generic application protocol for connection-oriented, asynchronous interactions. It permits simultaneous and independent exchanges within the context of a single application user-identity. It supports both textual and binary messages.


Overview

BEEP peers communicate with Messages over predefined Channels. Messages are generated by application defined Profiles. Before message is sent, and once message is received by the peer, Profile defines parsing to provide necessary information.

Messages

Messages are initiated by the application, and are prepared by defined Profile. Corresponding profile awaits on other side to parse the message and provide only necessary information.

Channels

All exchanges occur in the context of a channel -- a binding to a well-defined aspect of the application, such as transport security, user authentication, or data exchange.

Profiles

Each channel has an associated "profile" that defines the syntax and semantics of the messages exchanged. Implicit in the operation of BEEP is the notion of channel management. Except for few profiles defined internally in wodBeep, you can define your own profiles: for data exchange, tuning parameters etc.

Transport

A BEEP session is mapped onto an underlying transport service. It can be single TCP connection, but also UDP or any higher level two-way transport service - SMTP architecture... wodBeep implements TCP Transport for you - you can implement easily any other transport just by implementing IBeepTransport interface!

Although BEEP is peer-to-peer connection, it is convenient to label each peer to behave in context of a Listener (Server) or Initiator (Client).


Included profiles

wodBeep comes with several included profiles:

  • SINK / ECHO profiles for testing,
  • SYSLOG Raw and Cooked profiles for transmitting (and receiving) syslog messages
  • ZIP tuning profile that will compress contents of messages on the fly
  • ROT13 profile that will garble message data
